800W Less Power Outdoor Car Single Output Inverter Pure Sine Wave
  • 800W Less Power Outdoor Car Single Output Inverter Pure Sine Wave
  • 800W Less Power Outdoor Car Single Output Inverter Pure Sine Wave
  • 800W Less Power Outdoor Car Single Output Inverter Pure Sine Wave
Pure Sine Wave Inverter

800W Less Power Outdoor Car Single Output Inverter Pure Sine Wave

800W Less Power Pure Sine Wave Inverter

● 800W continuous pure sine wave power and 1600W surge power

● Ultra- clean pure sine wave power. With less than 3% total harmonic distortion.

● The inverter is lighter and more compact than others with similar power ratings because they use high-frequency switching technology in the power conversion process.

● 12 months warranty.

100% full continuous 800W pure sine wave power.Greater drive capability,better protection to sensitive equipment, less audible and electrical noise, less power consumption. Provide clean power and low interference to your devices. Smart cooling fan system makes more energy efficient and silent.Effectively prevent inverter from malfunction due to overheating.

Protecion Features

● Over voltage and under voltage protection

● Over temperature and over load protection

● Short circuit and reverse polarity protection

What you will get

A 800w pure sine wave inverter, 2x battery cables (black and red), a user manual, A car ignition port and a set spare fuses.

Contact Now Catalogue Download

Description

The user manual of pure sine wave inverters

Advantages:
1. Pure power output: The 800W Less Power Outdoor Car Single Output Inverter Pure Sine Wave uses advanced high-frequency switching technology to output 100% pure sine wave power, ensuring a total harmonic distortion rate of less than 3%. This means that your sensitive devices will be effectively protected during use, and the potential damage caused by power fluctuations will be greatly reduced, thereby ensuring stable operation of the equipment.
2. Lightweight and compact design: Our 800W Less Power Outdoor Car Single Output Inverter Pure Sine Wave is designed to be small and lightweight, easy to carry and install. Whether placed inside a vehicle or in an outdoor environment, it can easily adapt to add convenience to your outdoor adventures. This design not only improves portability, but also allows you to easily get the power you need in any occasion.
3. Intelligent cooling system: The built-in intelligent cooling fan system can automatically adjust according to the operating temperature of the inverter to ensure efficient heat dissipation and silent operation. This design effectively prevents equipment failures caused by overheating, improves energy efficiency and service life, and allows you to use it without worries for a long time.
4. Comprehensive protection mechanism: Our inverters are equipped with multiple protection mechanisms, including overvoltage, undervoltage, overtemperature, overload, short circuit and reverse connection protection. These protection measures ensure the safe operation of the inverter in various environments, and provide reliable power protection for your equipment even in harsh conditions.

Specification - 800W Pure Sine Wave Inverter
Model: YX-0.8KS-1-2 YX-0.8KS-2-2 YX-0.8KS-1-1 YX-0.8KS-2-1
12V model 24V model 12V model 24V model
DC Input Nominal Voltage: 12.5Vdc 25.0Vdc 12.5Vdc 25.0Vdc
DC Input Voltage Operating range: 10.5-16Vdc 21-32Vdc 10.5-16Vdc 21-32Vdc
DC Nominal Current at Full  load: 56Adc 26Adc 56Adc 26Adc
AC Output Operating Voltage Options: 230Vac 120Vac
AC Output waveform: True Sine wave
Continuous AC Output Power: 800W
Continuous AC Output Current: 2.6A 5.0A
Frequency: 50HZ 60HZ
Surge Power: 1600W
Peak Efficiency: 92% 93% 92% 93%
Full Load Efficieny: ≧88% ≧89% ≧88% ≧89%
AC Output Waveform(THD): ≦5.0%
No load Current: ≦1.0A ≦0.5A ≦1.0A ≦0.5A
Inver Off-Input Current: ≦0.5mA
USB Port: 5V / 2.1A
Ignition Control: Feature to turn inverter on/off via a 12Vdc signal and to minimize battery drain by switching the inverter off when the ignition key is turn off.
Protection Function: Under voltage protection, over voltage protection, over load protection, over temperature protection, short circuit protection, reverse polarity protection
Operating Temperature Range: -20ºC -- 60ºC
Storage Temperature Range: -40ºC -- 70ºC
Operating Humidity Range: 5 to 95 %RH, non-condensing
Net Weights: 1.5KG
Demensions LxWxH: 235x120x52mm
Cooling Way: Intelligent cooling fan
Warranty: 12months
Remote Panel (parts selection matching): Can show DC input voltage, AC output power, AC output voltage and error codes.
