300W Continuous Pure Sine Wave Inverter
  • 300W Continuous Pure Sine Wave Inverter
  • 300W Continuous Pure Sine Wave Inverter
  • 300W Continuous Pure Sine Wave Inverter
Pure Sine Wave Inverter

300W Continuous Pure Sine Wave Inverter

300W Continuous Pure Sine Wave Inverter

● 300W continuous pure sine wave power and 600W surge power.

● Ultra- clean pure sine wave power. With less than 3% total harmonic distortion.

● The inverter is lighter and more compact than others with similar power ratings because they use high-frequency switching technology in the power conversion process.

● 12 months warranty.


This is an inverter converting DC from your car battery to AC for whatever you want to use within its Watt range.It can pull power from the battery through the cigarette lighter plug or directly clamp the alligator battery clips onto the car battery.Plug this into 12v cigarette lighter outlet provides continuous DC to AC power with 2 AC outlets operates any 110v device and 2 USB ports which detects your device automatically to deliver its fastest charge speed up to 2.4 amps per port/4.2 amps max.

Protecion Features:

● Over voltage and under voltage protection

● Over temperature and over load protection

● Short circuit and reverse polarity protection



What you will get

A 300w pure sine wave inverter, 2x battery cables (black and red), a user manual, A car ignition port and a set spare fuses.

Contact Now Catalogue Download

Description

The user manual of pure sine wave inverters

Specification - 300W Pure Sine Wave Inverter
Model: YX-0.3KS-1-2 YX-0.3KS-2-2 YX-0.3KS-1-1 YX-0.3KS-2-1
12V model 24V model 12V model 24V model
DC Input Nominal Voltage: 12.5Vdc 25.0Vdc 12.5Vdc 25.0Vdc
DC Input Voltage Operating range: 10.5-16Vdc 21-32Vdc 10.5-16Vdc 21-32Vdc
DC Nominal Current at Full  load: 28Adc 13Adc 28Adc 13Adc
AC Output Operating Voltage Options: 230Vac 120Vac
AC Output waveform: True Sine wave
Continuous AC Output Power: 300W
Continuous AC Output Current: 1.3A 2.5A
Frequency: 50HZ 60HZ
Surge Power: 600W
Peak Efficiency: 92% 93% 92% 93%
Full Load Efficieny: ≧88% ≧89% ≧88% ≧89%
AC Output Waveform(THD): ≦5.0%
No load Current: ≦1.0A ≦0.5A ≦1.0A ≦0.5A
Inverter Off-Input Current: ≦0.5mA
USB Port: 5V / 2.1A
Ignition Control: Feature to turn inverter on/off via a 12Vdc signal and to minimize battery drain by switching the inverter off when the ignition key is turn off.
Protection Function: under voltage protection, over voltage protection, over load protection, over temperature protection, short circuit protection, reverse polarity protection
Operating Temperature Range: -20ºC -- 60ºC
Storage Temperature Range: -40ºC -- 70ºC
Operating Humidity Range: 5 to 95 %RH, non-condensing
Net Weights: 1.2KG
Demensions LxWxH: 210x120x52mm
Cooling Way: Intelligent cooling fan
Warranty: 18months
Remote Panel (parts selection matching): Can show DC input voltage, AC output power, AC output voltage and error codes.
